Hayward S230T 23" Sand Filter System 1.5-HP 2-Speed Matrix Pump

Hayward S230T 23" Sand Filter System 1.5-HP 2-Speed Matrix Pump
The Hayward S230T932S Pro Series sand filter system for above ground pools, offers excellent filtration with low maintenance. Read more
  • Ships within 1-3 business days
  • Free shipping
  • In Stock
Hayward S230T 23" Sand Filter System 1.5-HP 2-Speed Matrix Pump


  • Ideal for above ground pools up to 33' round and 21'x43' oval
  • Model# S230T932S sand filter system includes 23" filter tank, 7-way multiport valve, pressure gauge,1.5-HP 2 Speed Matrix Power-Flo pump, filter base, (2) 1 1/2" x 6' filter hoses, (1) clear pump-to-filter hose, hose adapters and clamps
  • Easy to use 7-way multiport vari-flo valve provides maximum flow - model SP0714T
  • System flow rate of 54 gallons per minute or 25,920 gallons in 8 hours
  • Includes 6' power cord with standard 115V plug
  • Pump Amperage: 11.0/2.9 Amps
  • 1.5-HP 2 Speed Matrix Power-Flo pump includes ON/OFF switch with Hi/Low settings (1.1 THP)
  • WEF (Weighted Energy Factor): 5.7 (5,700 gallons pumped per kWh)
  • Requires 250lbs of filter sand (not included)
  • 1-year limited manufacturer's Warranty
  • Assembled in the U.S.A. by Hayward Pool Products
  • Approximate outside dimensions of filter system: Length: 36", Width: 24", Height: 42"

California residents see prop65 warnings


The Hayward S230T Pro Series 2 speed sand filter system offers excellent filtration, efficiency, and low maintenance. Hayward sand filters use specially graded sand to help trap particles and debris, providing crystal clear pool water. The filter sand can last 5-10 years between changes giving you a very economical filtration system that is simple to operate.

Brand / Manufacturer


For over 80-years, Hayward has been helping pool owners enjoy the pleasures of pool ownership by manufacturing cutting edge, technologically advanced pool equipment worldwide. Hayward strive's to ensure that your Totally Hayward System operates at maximum efficiency all season long. Hayward's goal is that at the end of the day, your only concern is to turn your equipment on and off. Hayward provides the latest in pool pumps, filters, heaters, cleaners, controls, lighting, and salt chlorination.
